MODEL |
VOLTAGE |
NO LOAD |
AT MAXIMUM EFFICIENCY |
STALL |
OPERATING
RANGE |
NOMINAL |
SPEED |
CURRENT |
SPEED |
CURRENT |
TORQUE |
OUTPUT |
TORQUE |
CURRENT |
r/min |
A |
r/min |
A |
mN-m |
g.cm |
W |
mN.m |
g.cm |
A |
|
CMS-FC2025E-A-09490 |
8~16 |
12V CONSTANT |
7900 |
0.042 |
5910 |
0.12 |
1.03 |
10.5 |
0.63 |
4.07 |
41 |
0.37 |
|
CMS-FC2025E-B-061000 |
9~16 |
13.5V CONSTANT |
4300 |
0.028 |
2900 |
0.058 |
0.73 |
7.5 |
0.22 |
2.25 |
23 |
0.12 |
|
CMS-FC2025E-C-11240 |
10~16 |
13.5V CONSTANT |
12800 |
0.070 |
10270 |
0.28 |
1.82 |
18.6 |
1.96 |
9.21 |
94 |
1.15 |
|
| |
 |
|
|
|
|
|
