MODEL |
VOLTAGE |
NO LOAD |
AT MAXIMUM EFFICIENCY |
STALL |
OPERATING
RANGE |
NOMINAL |
SPEED |
CURRENT |
SPEED |
CURRENT |
TORQUE |
OUTPUT |
TORQUE |
CURRENT |
r/min |
A |
r/min |
A |
mN-m |
g.cm |
W |
mN.m |
g.cm |
A |
|
CMS-RF2420-A-07800 |
1~3 |
1.5V CONSTANT |
800 |
0.004 |
570 |
0.010 |
0.083 |
0.84 |
0.005 |
0.29 |
3.0 |
0.025 |
|
CMS-RF2420-A-13330 |
1.3~13.0 |
4V CONSTANT |
3600 |
0.020 |
3000 |
0.10 |
0.78 |
7.9 |
0.24 |
4.70 |
48 |
0.51 |
|
CMS-RF2420-A-09500 |
2~8 |
4.5V CONSTANT |
3300 |
0.010 |
2700 |
0.045 |
0.40 |
4.1 |
0.11 |
2.21 |
23 |
0.20 |
|
| |
 |
|
|
|
|
|
