MODEL |
VOLTAGE |
NO LOAD |
AT MAXIMUM EFFICIENCY |
STALL |
OPERATING
RANGE |
NOMINAL |
SPEED |
CURRENT |
SPEED |
CURRENT |
TORQUE |
OUTPUT |
TORQUE |
CURRENT |
r/min |
A |
r/min |
A |
mN-m |
g.cm |
W |
mN.m |
g.cm |
A |
|
CMS-RS4760P-A-4540(*1) |
9~36 |
18V CONSTANT |
10000 |
0.85 |
8400 |
4.47 |
61.8 |
630 |
54.3 |
387 |
3945 |
23.5 |
|
CMS-RS4760P-B-8016(*1) |
6.0~14.4 |
14.4V CONSTANT |
20500 |
2.40 |
17730 |
15.3 |
94.2 |
960 |
175 |
696 |
7095 |
98.0 |
|
CMS-RS4760P-C-24120(*2) |
12~27 |
24V CONSTANT |
3500 |
0.22 |
2840 |
0.95 |
45.9 |
468 |
13.6 |
244 |
2487 |
4.10 |
|
CMS-RS4760P-D-8017(*3) |
6~20 |
18V CONSTANT |
19800 |
2.30 |
17320 |
16.0 |
126 |
1289 |
229 |
1009 |
10285 |
112 |
|
| |
 |
|
|
|
|
|
