MODEL |
VOLTAGE |
NO LOAD |
AT MAXIMUM EFFICIENCY |
STALL |
OPERATING
RANGE |
NOMINAL |
SPEED |
CURRENT |
SPEED |
CURRENT |
TORQUE |
OUTPUT |
TORQUE |
CURRENT |
r/min |
A |
r/min |
A |
mN-m |
g.cm |
W |
mN.m |
g.cm |
A |
|
CMS-FA2430-A-2865 |
1.5~3.0 |
3V CONSTANT |
10500 |
0.17 |
8820 |
0.89 |
1.79 |
18.3 |
1.65 |
11.2 |
114 |
4.68 |
|
CMS-FA2430-B-20120 |
1.5~4.5 |
3V CONSTANT |
5900 |
0.080 |
4790 |
0.35 |
1.18 |
12.0 |
0.59 |
6.27 |
64 |
1.50 |
|
CMS-FA2430-C-2485 |
1.5~3.0 |
3V CONSTANT |
8000 |
0.13 |
6600 |
0.61 |
1.54 |
15.7 |
1.06 |
8.83 |
90 |
2.90 |
|
CMS-FA2430-D-4030 |
1.5~3.0 |
1.5V CONSTANT |
7800 |
0.37 |
6540 |
1.92 |
2.29 |
23.4 |
1.57 |
14.2 |
145 |
10.0 |
|
| |
 |
|
|
|
|
|
