MODEL |
VOLTAGE |
NO LOAD |
AT MAXIMUM EFFICIENCY |
STALL |
OPERATING
RANGE |
NOMINAL |
SPEED |
CURRENT |
SPEED |
CURRENT |
TORQUE |
OUTPUT |
TORQUE |
CURRENT |
r/min |
A |
r/min |
A |
mN-m |
g.cm |
W |
mN.m |
g.cm |
A |
|
CMS-RS3550-A-4522(*1) |
3.6~12.0 |
12V CONSTANT |
27800 |
1.30 |
22940 |
6.14 |
19.4 |
198 |
46.5 |
111 |
1131 |
29.0 |
|
CMS-RS3550-B-5018(*1) |
4.5~12.0 |
12V CONSTANT |
24000 |
1.30 |
20510 |
7.65 |
31.1 |
317 |
66.7 |
214 |
2181 |
45.0 |
|
CMS-RS3550-C-18150(*1) |
12~32 |
30V CONSTANT |
7000 |
0.13 |
5720 |
0.58 |
18.2 |
185 |
10.9 |
99.2 |
1011 |
2.59 |
|
| |
 |
|
|
|
|
|
