MODEL |
VOLTAGE |
NO LOAD |
AT MAXIMUM EFFICIENCY |
STALL |
OPERATING
RANGE |
NOMINAL |
SPEED |
CURRENT |
SPEED |
CURRENT |
TORQUE |
OUTPUT |
TORQUE |
CURRENT |
r/min |
A |
r/min |
A |
mN-m |
g.cm |
W |
mN.m |
g.cm |
A |
|
CMS-FA2426-A-2670 |
1.5~3.0 |
1.5V CONSTANT |
6300 |
0.15 |
5080 |
0.62 |
0.99 |
10.1 |
0.52 |
5.10 |
52 |
2.60 |
|
CMS-FA2426-B-2295 |
1.5~4.5 |
3V CONSTANT |
9400 |
0.14 |
7680 |
0.63 |
1.26 |
12.8 |
1.01 |
6.87 |
70 |
2.80 |
|
CMS-FA2426-C-20120 |
1.5~4.5 |
4.5V CONSTANT |
10800 |
0.12 |
8920 |
0.57 |
1.45 |
14.8 |
1.35 |
8.33 |
85 |
2.70 |
|
| |
 |
|
|
|
|
|
