MODEL |
VOLTAGE |
NO LOAD |
AT MAXIMUM EFFICIENCY |
STALL |
OPERATING
RANGE |
NOMINAL |
SPEED |
CURRENT |
SPEED |
CURRENT |
TORQUE |
OUTPUT |
TORQUE |
CURRENT |
r/min |
A |
r/min |
A |
mN-m |
g.cm |
W |
mN.m |
g.cm |
A |
|
CMS-RK2430-A-10800 |
12~30 |
24V CONSTANT |
5100 |
0.015 |
4310 |
0.082 |
2.58 |
26.3 |
1.16 |
16.7 |
170 |
0.45 |
|
CMS-RK2430-B-18260 |
6~18 |
13V CONSTANT |
8500 |
0.055 |
7370 |
0.36 |
3.52 |
35.8 |
2.71 |
26.5 |
270 |
2.35 |
|
CMS-RK2430-C-081050 |
12~30 |
24V CONSTANT |
3900 |
0.010 |
3210 |
0.047 |
1.90 |
19.3 |
0.64 |
10.8 |
110 |
0.22 |
|
| |
 |
|
|
|
|
|
