MODEL |
VOLTAGE |
NO LOAD |
AT MAXIMUM EFFICIENCY |
STALL |
OPERATING
RANGE |
NOMINAL |
SPEED |
CURRENT |
SPEED |
CURRENT |
TORQUE |
OUTPUT |
TORQUE |
CURRENT |
r/min |
A |
r/min |
A |
mN-m |
g.cm |
W |
mN.m |
g.cm |
A |
|
CMS-RE2430-A-2865 |
1.5~3.0 |
3V CONSTANT |
9200 |
0.16 |
7770 |
0.87 |
1.98 |
20.2 |
1.61 |
12.7 |
129 |
4.70 |
|
CMS-RE2430-B-20120 |
3~6 |
4.5V CONSTANT |
7500 |
0.080 |
6300 |
0.42 |
1.77 |
18.1 |
1.17 |
11.1 |
113 |
2.21 |
|
CMS-RE2430-C-2485 |
1.5~4.5 |
3V CONSTANT |
7000 |
0.12 |
5800 |
0.58 |
1.68 |
17.1 |
1.02 |
9.80 |
100 |
2.80 |
|
CMS-RE2430-D-2865 |
1.5~4.5 |
3V CONSTANT |
7100 |
0.16 |
6000 |
0.88 |
2.58 |
26.3 |
1.62 |
16.7 |
170 |
4.80 |
|
CMS-RE2430-E-20120 |
3~6 |
4.5V CONSTANT |
5800 |
0.080 |
4890 |
0.43 |
2.26 |
23.1 |
1.16 |
14.5 |
148 |
2.34 |
|
CMS-RE2430-F-2485 |
3~6 |
4.5V CONSTANT |
8100 |
0.13 |
6880 |
0.73 |
2.74 |
27.9 |
1.97 |
18.1 |
185 |
4.10 |
|
| |
 |
|
|
|
|
|
