MODEL |
VOLTAGE |
NO LOAD |
AT MAXIMUM EFFICIENCY |
STALL |
OPERATING
RANGE |
NOMINAL |
SPEED |
CURRENT |
SPEED |
CURRENT |
TORQUE |
OUTPUT |
TORQUE |
CURRENT |
r/min |
A |
r/min |
A |
mN-m |
g.cm |
W |
mN.m |
g.cm |
A |
|
CMS-RE2326-A-2670 |
1.5~3.0 |
1.5V CONSTANT |
6300 |
0.16 |
5040 |
0.64 |
0.98 |
10.0 |
0.52 |
4.90 |
50 |
2.56 |
|
CMS-RE2326-B-18130 |
1.5~4.5 |
3V CONSTANT |
6900 |
0.095 |
5470 |
0.36 |
0.97 |
9.9 |
0.56 |
4.70 |
48 |
1.40 |
|
CMS-RE2326-C-2295 |
1.5~4.5 |
3V CONSTANT |
9400 |
0.15 |
7610 |
0.64 |
1.31 |
13.3 |
1.04 |
6.86 |
70 |
2.70 |
|
| |
 |
|
|
|
|
|
