MODEL |
VOLTAGE |
NO LOAD |
AT MAXIMUM EFFICIENCY |
STALL |
OPERATING
RANGE |
NOMINAL |
SPEED |
CURRENT |
SPEED |
CURRENT |
TORQUE |
OUTPUT |
TORQUE |
CURRENT |
r/min |
A |
r/min |
A |
mN-m |
g.cm |
W |
mN.m |
g.cm |
A |
|
CMS-RC2430-A-2865 |
4.5~6.0 |
4.5V CONSTANT |
13600 |
0.27 |
11350 |
1.36 |
2.92 |
29.8 |
3.47 |
17.7 |
180 |
6.90 |
|
CMS-RC2430-B-20120 |
4.5~9.0 |
6V CONSTANT |
9900 |
0.12 |
8210 |
0.58 |
2.26 |
23.0 |
1.94 |
13.2 |
135 |
2.82 |
|
CMS-RC2430-C-2485 |
4.5~8.4 |
7.2V CONSTANT |
16800 |
0.21 |
14260 |
1.18 |
3.27 |
33.3 |
4.87 |
21.6 |
220 |
6.60 |
|
CMS-RC2430-D-2865 |
4.5~9.0 |
6V CONSTANT |
14000 |
0.28 |
11910 |
1.60 |
4.46 |
45.5 |
5.56 |
29.9 |
305 |
9.10 |
|
CMS-RC2430-E-20120 |
4.5~12.0 |
12V CONSTANT |
15500 |
0.15 |
13320 |
0.92 |
4.68 |
47.7 |
6.52 |
33.3 |
339 |
5.60 |
|
CMS-RC2430-F-2485 |
4.5~9.6 |
6V CONSTANT |
10800 |
0.18 |
9130 |
0.99 |
3.71 |
37.8 |
3.54 |
24.0 |
245 |
5.40 |
|
| |
 |
|
|
|
|
|
