MODEL |
VOLTAGE |
NO LOAD |
AT MAXIMUM EFFICIENCY |
STALL |
OPERATING
RANGE |
NOMINAL |
SPEED |
CURRENT |
SPEED |
CURRENT |
TORQUE |
OUTPUT |
TORQUE |
CURRENT |
r/min |
A |
r/min |
A |
mN-m |
g.cm |
W |
mN.m |
g.cm |
A |
|
CMS-FF1015-A-8Z130 |
2~3 |
3V CONSTANT |
15200 |
0.045 |
11820 |
0.16 |
0.16 |
1.7 |
0.20 |
0.74 |
7.5 |
0.55 |
|
CMS-FF1015-B-1255 |
1.2~2.0 |
1.5V CONSTANT |
17100 |
0.094 |
13300 |
0.33 |
0.15 |
1.6 |
0.21 |
0.69 |
7.0 |
1.15 |
|
CMS-FF1015-C-7Z170 |
2~4 |
2V CONSTANT |
8000 |
0.025 |
5980 |
0.074 |
0.091 |
0.93 |
0.057 |
0.36 |
3.7 |
0.22 |
|
CMS-FF1015-D-8Z165 |
1.4~4.0 |
2V CONSTANT |
8400 |
0.027 |
6410 |
0.087 |
0.11 |
1.1 |
0.075 |
0.47 |
4.8 |
0.28 |
|
CMS-FF1015-E-07210 |
3~5 |
4.7V CONSTANT |
17300 |
0.032 |
13330 |
0.11 |
0.16 |
1.7 |
0.23 |
0.71 |
7.2 |
0.36 |
|
CMS-FF1015-F-09140 |
2.0~4.5 |
2.8V CONSTANT |
15500 |
0.045 |
11980 |
0.15 |
0.16 |
1.6 |
0.20 |
0.69 |
7.0 |
0.52 |
|
| |
 |
|
|
|
|
|
