MODEL |
VOLTAGE |
NO LOAD |
AT MAXIMUM EFFICIENCY |
STALL |
OPERATING
RANGE |
NOMINAL |
SPEED |
CURRENT |
SPEED |
CURRENT |
TORQUE |
OUTPUT |
TORQUE |
CURRENT |
r/min |
A |
r/min |
A |
mN-m |
g.cm |
W |
mN.m |
g.cm |
A |
|
CMS-FC2430PS-A-20150 |
9~15 |
12V CONSTANT |
12000 |
0.10 |
10360 |
0.63 |
4.22 |
43.0 |
4.57 |
30.9 |
315 |
4.00 |
|
CMS-FC2430PS-B-18165 |
9~15 |
12V CONSTANT |
11000 |
0.10 |
9330 |
0.56 |
4.24 |
43.2 |
4.13 |
27.9 |
284 |
3.12 |
|
CMS-FC2430PS-C-18165 |
10~15 |
12V CONSTANT |
12400 |
0.090 |
10660 |
0.55 |
3.57 |
36.4 |
3.98 |
25.5 |
260 |
3.40 |
|
CMS-FC2430PS-D-16200 |
10~15 |
12V CONSTANT |
10000 |
0.070 |
8470 |
0.39 |
3.30 |
33.7 |
2.92 |
21.6 |
220 |
2.15 |
|
CMS-FC2430PS-E-4523 |
1~2 |
1.2V CONSTANT |
8700 |
0.58 |
7100 |
2.58 |
2.42 |
24.7 |
1.80 |
13.2 |
135 |
11.5 |
|
| |
 |
|
|
|
|
|
