MODEL |
VOLTAGE |
NO LOAD |
AT MAXIMUM EFFICIENCY |
STALL |
OPERATING
RANGE |
NOMINAL |
SPEED |
CURRENT |
SPEED |
CURRENT |
TORQUE |
OUTPUT |
TORQUE |
CURRENT |
r/min |
A |
r/min |
A |
mN-m |
g.cm |
W |
mN.m |
g.cm |
A |
|
CMS-FC2430E-A-20150 |
8~15 |
12V CONSTANT |
11800 |
0.081 |
10310 |
0.56 |
4.14 |
42.2 |
4.47 |
32.9 |
335 |
3.90 |
|
CMS-FC2430E-B-18180 |
8~15 |
12V CONSTANT |
9700 |
0.16 |
7880 |
0.69 |
5.33 |
54.3 |
4.39 |
28.4 |
290 |
3.00 |
|
CMS-FC2430E-C-16200 |
9~14 |
12V CONSTANT |
8700 |
0.060 |
7420 |
0.35 |
3.40 |
34.6 |
2.63 |
23.0 |
234 |
2.00 |
|
| |
 |
|
|
|
|
|
