MODEL |
VOLTAGE |
NO LOAD |
AT MAXIMUM EFFICIENCY |
STALL |
OPERATING
RANGE |
NOMINAL |
SPEED |
CURRENT |
SPEED |
CURRENT |
TORQUE |
OUTPUT |
TORQUE |
CURRENT |
r/min |
A |
r/min |
A |
mN-m |
g.cm |
W |
mN.m |
g.cm |
A |
|
CMS-FC2426-A-2670 |
3~6 |
4.5V CONSTANT |
14000 |
0.27 |
11660 |
1.34 |
2.94 |
30.0 |
3.59 |
17.6 |
179 |
6.70 |
|
CMS-FC2426-B-10300 |
6.0~26.5 |
26.5V CONSTANT |
19000 |
0.080 |
15470 |
0.35 |
3.19 |
32.5 |
5.16 |
17.2 |
175 |
1.54 |
|
CMS-FC2426-C-12250 |
6~28 |
24V CONSTANT |
20600 |
0.080 |
17530 |
0.46 |
3.51 |
35.7 |
6.43 |
23.5 |
240 |
2.60 |
|
| |
 |
|
|
|
|
|
